AGFRC B13DLM V2 SERVO            PURCHASE LINK

AGFRC B13DLM V2 servo is programmable digital servo. Combine with double ball bearings, titanium gear and DC motor, to provide high torque. Support to program the servo parameter via our USB Programmer to meet different needs.

Ideal for RC Crawler, Airplane, 450 Size Helicopter etc.

FEATURES

• Plastic and Aluminum Case

• High Precision Metal Gears

• High Quality Brushed Motor

• High Performance Programmable Digital Servo

PRODUCT SPECIFICATIONS

   Voltage    4.8V ~ 8.4V    Direction    CCW

   Gear Material    Titanium | Copper    Temperature    -15°C ~ +70°C

   Pulse Width    500 ~ 2500 µSec    Refresh Rate    1520 µS / 333Hz

   Dimension    22.8*12*29.4 mm    Motor Type    DC

   Bearing    2BB    Dead Band    3 µSec

   Net Weight    17 g    Gear Spline    25T-ɸ4.94 mm

   Case Material    AL+Plastic    Travel Angel    180° ± 10°

   Wire    JR 180mm / 26AWG    Wire Color    Black | Red | White

Operating Speed     Stall Torque

0.150 sec/60° @4.8V     3.0 kg·cm (42 oz·in) @4.8V

0.130 sec/60° @6.0V     3.8 kg·cm (53) @6.0V

0.110 sec/60° @7.4V     4.2 kg·cm (58 oz·in) @7.4V

0.100 sec/60° @8.4V     4.5 kg·cm (63 oz·in) @8.4V
